| Model | GDF-40C120 | GDF-40C500 |
| Volume (L/cu.ft.) | 120/3.7 | 500/17.12 |
| Shelves or Drawers Qty (height adjustable) | / | / |
| Chamber Size (mm) | 480*380*665 | 1455*525*665 |
| Outer Size (mm) | 685*645*930 | 1670*810*930 |
| Package Size (mm) | 750*700*1040 | 1775*880*1060 |
| Net Weight/Gross Weight (kg) | 52/64.5 | 108/135 |
| CBM | 0.55 | 1.66 |
| 20GP/40GP/40HQ | 24/51/51 | 6/13/13 |
| Performance | ||
| Cooling Performance | -40℃ | -40℃ |
| Temperature Control Range | -10～-40℃ | -20～-40℃ |
| Ambient Temperature | 10℃ to 32℃ | 10℃ to 32℃ |
| Control | ||
| Controller | Microprocessor | Microprocessor |
| Display | Digital Display | Digital Display |
| Temperature Sensor | NTC | NTC |
| Refrigeration | ||
| Refrigeration System | Direct cooling method | |
| Compressors | CUBIGEL/1 | CUBIGEL/1 |
| Condenser | Wire tube | Wire tube |
| Refrigerant | R290 | R290 |
| Insulation Material and Thickness | PURF | |
| Construction | ||
| Outer Material | Painted Steel | |
| Chamber Material | Stainless Steel | |
| Outer Door | Foam, Sealing joint strip | |
| Outer Door Lock | Safety door lock and | |
| Inner Door Qty | / | / |
| Test Port Qty & Diameter | 1/25MM | Optional |
| Casters | Y | Y |
| Audiable and Visual Alarms | ||
| High & Low Temperature | Y | Y |
| Extremely High Ambient | / | / |
| Thermostat Failure | Y | Y |
| Sensor Error | Y | Y |
| Abnormal Voltage | / | / |
| Power Failure | Y | Y |
| Low Battery | / | / |
| Condenser Clean | / | / |
| Filter Clean | / | / |
| Door Open | / | / |
| Romote Alarm | / | / |
| Electrical and Noise Level | ||
| Power Supply | 220V/50/60HZ, 110V/60Hz | |
| Heat Output (220V) | 160W | 295W |
| Power Consumption (KWh/24hr) | 1.65 | 3.45 |
| Noise Level | 50 | 55 |
| Options | ||
| USB Port | / | / |
| Chart Recorder | / | / |
| Data Logger | Optional | Optional |
| Power Failure Backup Battery | / | / |
| CO2 or LN2 Back-up | Optional | Optional |
