CHARACTERISTICS
| Model | GBP-5 | GBP-10 |
| Size | ||
| Trays | 5 | 10 |
| Capacity of Blood Bags(450ml) | 10/5 layers | 20/10 layers |
| N.T./G.T.(kg) | 60/65 | 80/86 |
| Exterior Size(W*D*H)(mm) | 427*360*467 | 432*462*728 |
| Interior Size(W*D*H)(mm) | 522*600*1050 | 522*600*1300 |
| Package Size(W*D*H)(mm) | 585*700*1205 | 588*677*1440 |
| Performance | ||
| Temperature Range(℃) | 20~24℃ | |
| Temperature Accuracy(℃) | 0.1℃ | |
| Climate/ Ambient Temp.(℃) | SN (10-32℃) | |
| Noise(db) | 49 | 50 |
| Refrigeration System | ||
| Refrigerant | CFC-free, R134a | |
| Cooling | Forced air cooling | |
| Defrost | No frost | |
| Compressor Brand/Qty | Embraco/1 | |
| Insulation | PU | |
| Control System | ||
| Temperature Controller | Microprocessor | |
| Sensor | NTC | |
| Display | Digital LED display | |
| Power | ||
| Voltage Frequency(V/Hz) | 220V, 50/60Hz | |
| Power Consumption(kWh/24h) | 2.69 | 4.4 |
| Power(W) | 197W | 280W |
| Current(A) | 0.9 | 1.27 |
| Construction | ||
| Standard Shelf/drawer SS: Stainless steel | Stainless steel drawer | |
| Inside Material | SUS | |
| Outside Material | Anti-corrosion Painted Steel | |
| Outer Door Glass | (Foamed glass door | |
| Caster | Standard | |
| Audible and Visual Alarms | ||
| High/Low Temperature | Standard | |
| Sensor Failure | Standard | |
| Door Ajar | Standard | |
| Power off | Standard | |
| Backup Battery Malfunction | Standard | |
| Accessories | ||
| Light | UV Light | |
| Test Hole | Optional | |
| Temperature Recorder | Optional | |
DESCRIPTION
| BOX | • SUS oscillator, mirror surface SUS shelves • Box foamed with high density non-CFC material, reasonable design of air duct in the cabinet, axial flow fan makes inner temperature more uniformity with accurate temperature control | PURPOSE | • To store blood platelet(20℃-40℃), biological reagent(2℃-40℃), chemical products stored at(2℃-40℃) • Suitable for hospitals,blood stations, research institutes and university labs |
| SAFETY SYSTEM | • Imported oscillation slide rail for longevity and low noise • High/low temperature alarm, sensor error alarm, power failure alarm for 72hours, low batery alarm, door ajar alarm • Two alarm systems: audible buzzing and visual flashing light • Power cord with earth leakage prorection | TEMPERATURE CONTROL MODE | • High accuracy sensor • Microprocessor temperature control, inner temperature controlled 22℃±2℃ • Intelligent controlled fan with forced cycle system to ensure inner temperature more uniform |
| CHARACTERISTIC FUNCTION | • Disinfection with UV, set disinfection time freely, UV light would be off while door open, to protect human body • Temperature printer can be set as needed • Wide voltage from 187V-242V • Power on/off switch, more convenient for operation • Double transparent insulated glass door for easy observation • Big digital display for easy observation | REFRIGERATION SYSREM | • Branded condenser fan • Branded compressor with CFC-free refrigerant • High efficiency refrigeration system, fast cooling speed and uniformity temperature inside • Branded evaporator for safety and longevity • Finned evaporator to speed up the cooling process |
