Energy Saving Design
●According to environment and load capacity, auto adjustment to achieve the optimal heating mode and reduce energy consumption.
●New synthetic silica gel seal provides exceptional sealing with heat loss prevention and 25% energy saving.
Internal Circulation System
●Solenoid valve replaces manual knob, avoids the first shutdown of the vacuum pump makes the pump oil sucked backward to chamber.
●Turbine suction fan and plates with heat dissipating holes, give higher ventilation and better temperature uniformity.
●Vacuum pump with power socket and solenoid valve switch control
●Solenoid valve air-exhaust is switch controlled.
●LCD display of real-time parameters, and menu setting of temperature, illumination and time
●Detachable and height-adjustable plates with min height of 30mm
●Slide-way bayonet prevents the plates tilt and dislocation.
●Radiable heating ensures temperature uniformity.
●Large arc angle, easy to clean and maintain
●Display of "END" with buzz reminder
●Power off memory
●Limited temperature alarm system: auto-stop if limited temperature exceeds and auto audible and visual alarm if alarm-temperature exceeds.
●Electric leakage protection device ensures the safety of the operator and other equipment in the laboratory.
●Double-layer airtight door with inner toughened glass and outer bio-glass window,
●Self diagnostic function: display fault information and facilitate troubleshooting.
|Plate Qty (Height Adjustable)||1||2||2||2|
|Chamber Size (mm)||300*300*275||415*370*345||415*370*345||450*450*450|
|Outer Size (mm)||500*450*790||610*510*850||610*510*850||660*600*1500|
|Package Size (mm)||570*620*950||730*630*1010||730*630*1010||780*720*1660|
|Net Weight/Gross Weight (kg)||40/45||60/70||55/65||160/175|
|Temperature Control Range||RT+10~200℃||RT+10~200℃||Vacuum only, no heating||RT+10~200℃|
|Ambient Temperature||5℃ ~ 40℃|
|Heating Pipe||Stainless steel|
|Outer Material||Laser-cutting cold-rolled steel with anti-static spraying|
|Chamber Material||Corrosion-resistant brushed stainless steel |
|Plate||One-time formed 304 stainless steel entire plate, no welding spot;|
Load-bearing beam at the bottom, gives strong bearing capacity.
|Insulation||High quality aluminum silicate flutter cotton.|
|Observation Window||Double-layer toughened glass window with rubber ring|
|Electrical and Noise Level|
|Power Consumption||500W||1440W||No heating||2800W|
|Standard||Electric leakage protection, Vacuum pump filters|
|1.Φ 25mm/Φ 50mm/Φ 80mm test holes|
|2.Multi-segment programmable controller|
|3.Independent temperature limiting controller|
|4.USB Port OR Printer OR RS232 OR RS485 and communication software|
