CHARACTERISTICS
Measure principle steps of the whole Kjeldahl analyzing process are shown as follows (Kjeldahl nitrogen determination principle)
Semi-automatic Kjeldahl Nitrogen Analyzer is designed to finish the distillation step. Titration is manual operation.
1. Control of distillation and water level.
2. Auto power off if control system failure.
3. Minimalist design simplify the operation, no language barrier.
4. 15-year authorized convincing market approval, stable performance
5. Widely adaptable water source: tap water, low requirements for experiments.
6. Material: Shell of prayed steel plate, the work area with ABS anti-corrosion panel, resistant of chemicals of acid and alkali.
7. Safety Alarms Design: digestion tube safety door device, steam generator water shortage alarm, water level detection fault alarm.
DESCRIPTION
| Model | GKD-A001 |
| Working Mode | Semi-automatic |
| Measure Range | 0.1~200mgN (nitrogen content 0.1%-99%). |
| Measure Variety | Foodstuff, feedstuff, foods, dairy products, drink, soil, water, medicine, precipitate, chemical. |
| Measure Quantity | Adopt single distillation. |
| Recovery Rate | ≥99% (relative error, include digestion process) |
| Repetition Rate | Relative standard deviation＜±1% |
| Working Time | Distillation time: 5-15 minutes. (According to different samples, time required is also different.) |
| Cooling Water Consumption | Distillation: 3L/min (Water temperature is less than 20℃) |
| Distillation Consumtion | 1000W |
| Voltage | AC 220V/50HZ |
| Package Size | 790*450*370mm |
| Gross Weight | 25kg |
