Product Gallery
Características
| Model | GUL-86U60E | GUL-86U188E | GUL-86U340E | GUL-86U408E | GUL-86U588E | GUL-86U728E | GUL-86U838E |
| Volume (L/cu.ft.) | 60/2.12 | 188/6.63 | 340/12 | 408/14.4 | 588/20.76 | 728/25.7 | 838/29.59 |
| Stainless Steel Shelves Qty (height adjustable) | 1 | 2 | 3 | 3 | 3 | 3 | 3 |
| Load of Racks | 2 (6*2) | 9 (4*3) | 12 (4*4) | 16 (5*4, 4*4) | 16 (5*5) | 18(5*4) +6(6*4) | 24 (5*5) |
| Load of Boxes (2inches) | 24 | 108 | 192 | 288 | 400 | 504 | 600 |
| Max Load of Samples (2ml) | 2400 | 10800 | 19200 | 28800 | 40000 | 50400 | 60000 |
| Chamber Size (mm) | 330*453*410 | 465*465*830 | 488*607*1140 | 606*575*1180 | 606*738*1310 | 963*558*1350 | 894*718*1310 |
| Outer Size (mm) | 635*757*1212 | 850*930*1595 | 875*980*1900 | 890*930*1945 | 880*1090*1995 | 1260*890*2010 | 1175*1075*1990 |
| Package Size (mm) | 730*845*1400 | 880*910*1820 | 935*1070*2130 | 955*955*2100 | 970*1140*2190 | 1320*970*2190 | 1270*1100*2185 |
| Net Weight/Gross Weight (kg) | 87/115 | 174/224 | 222/284 | 234/291 | 290/360 | 360/402 | 344/430 |
| CBM | 0.86 | 1.46 | 2.13 | 1.92 | 2.42 | 2.8 | 3.05 |
| 20GP/40GP/40HQ | 22/48/48 | 12/26/26 | 12/24/24 | 12/24/24 | 12/24/24 | 8/18/18 | 8/18/18 |
| Performance | |||||||
| Cooling Performance | -86℃ | ||||||
| Temperature Control Range | -40~-86℃ | ||||||
| Pull Down Time to -86℃ at 30℃ | 4.5hrs | ||||||
| Ambient Temperature | 10℃ to 32℃ | ||||||
| Control | |||||||
| Controller | Microprocessor | ||||||
| Display | Digital LED display with all data | ||||||
| Temperature Sensor | PTC | ||||||
| Refrigeration | |||||||
| Refrigeration System | Self-cascade system | ||||||
| Compressors | SECOP/1 | CUBIGEL/1 | SECOP/1 | SECOP/1 | SECOP/2 | SECOP/2 | SECOP/2 |
| Refrigerant | Efficient Mixed-gas | ||||||
| Insulation Material and Thickness | 130mm PURF, Vacuum Insulation Panel Plus | ||||||
| Construction | |||||||
| Outer Material | Painted Steel | ||||||
| Chamber Material | Stainless Steel | ||||||
| Outer Door | Foamed with high quality VIP, Sealing joint strip with magnetic force. | ||||||
| Outer Door Lock | Safety door lock and password protection | ||||||
| Inner Door Qty | 1 | 3 | 2 | 2 | 2 | 2 | 2 |
| Test Port Qty & Diameter | 1/25mm | 1/25mm | 1/25mm | 1/25mm | 1/25mm | 1/25mm | 1/25mm |
| Casters | Y | Y | Y | Y | Y | Y | Y |
| Audiable and Visual Alarms | |||||||
| High & Low Temperature | Y | Y | Y | Y | Y | Y | Y |
| Extremely High Ambient | Y | Y | Y | Y | Y | Y | Y |
| Thermostat Failure | Y | Y | Y | Y | Y | Y | Y |
| Sensor Error | Y | Y | Y | Y | Y | Y | Y |
| Abnormal Voltage | Y | Y | Y | Y | Y | Y | Y |
| Power Failure | Y | Y | Y | Y | Y | Y | Y |
| Low Battery | Y | Y | Y | Y | Y | Y | Y |
| Condenser Clean | Y | Y | Y | Y | Y | Y | Y |
| Filter Clean | Y | Y | Y | Y | Y | Y | Y |
| Door Open | Y | Y | Y | Y | Y | Y | Y |
| Romote Alarm Port | Y | Y | Y | Y | Y | Y | Y |
| Electrical and Noise Level | |||||||
| Power Supply | 220V/50/60HZ, 110V/60Hz | ||||||
| Heat Output (220V) | 442W | 660W | 810W | 890W | 1500W | 1400W | 1700W |
| Power Consumption (KWh/24hr) | 5.6 | 8.2 | 11.2 | 12 | 16.5 | 20 | 18.8 |
| Noise Level | 49.5 | 52 | 52 | 50 | 53 | 53 | 55 |
| Options | |||||||
| USB Port | Y | Y | Y | Y | Y | Y | Y |
| Chart Recorder | / | / | / | / | / | / | / |
| Data Logger | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
| Power Failure Backup Battery | / | 72h | 72h | 72h | 72h | 72h | 72h |
| CO2 or LN2 Back-up | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
